C-More CM5 HMI Click PLC Tags Import

Автор: ACC Automation: PLC & Industrial Control Learning

Загружено: 2024-09-08

Просмотров: 1575

Описание: The C-More CM5 HMI programming software will allow tags to be imported. This can save you hours of work when establishing communications with different PLC controllers. Instead of creating and labeling tags in the PLC and the HMI, we can export them from the PLC and import them into the HMI. This saves you time, money, and mistakes.
We will be exporting tags from a Click PLC start-stop circuit. The export tags will then be imported into our HMI program. We will program a start-stop jog circuit on our C-More CM5 HMI screen. Let's get started.

More information can be obtained at our website. This includes all of the links mentioned in this video.
https://accautomation.ca/c-more-cm5-h...

00:00 C-More CM5 HMI Click PLC Tags Import
00:57 Modification of Click PLC program for CM5 HMI
02:57 Export Program Tags from the Click PLC
04:04 Start a New Project in the C-more HMI Programming Software
04:59 Import the Click PLC Tags into the C-More CM5 HMI
06:42 Program the C-More CM5 HMI
07:30 Transfer and Test the C-More HMI / Click PLC Program

The C-More CM5 HMI series can be found at this URL:
https://accautomation.ca/series/c-mor...

C-More CM5 Quick Features:
4″, 7″, 10″, 12″, 15″, and 22″ widescreen options
16.7M colors and LED backlights
800MHz or 1.6GHz Quad Core CPU
43MB project memory
12 to 24 VDC powered
Built-in real-time clock with 30-day backup (no battery required)
NEMA 4/4X (indoor use only), IP65
FREE HMI programming software with powerful design tools and a project simulator
CM5 series HMIs support any EA9 series project (created with V6.73 or later) for an easy panel upgrade

Support Links:
C-More CM5 Frequently Asked Questions (FAQ)
https://accautomation.ca/series/c-mor...
CM5-T7W Cut Sheet - Tech Specifications / Protocols
https://cdn.automationdirect.com/stat...
C-more CM5 Overview
https://cdn.automationdirect.com/stat...
CM5 User Manual - Hardware
https://cdn.automationdirect.com/stat...
CM5 Quick Start Guide
https://cdn.automationdirect.com/stat...
Product Brochure
https://cdn.automationdirect.com/stat...
C-More Programming Software (CM5 Series)
https://www.automationdirect.com/supp...
CM5 User Manual - Software On-Line
https://www.automationdirect.com/c-mo...
AD C-More CM5 Sample Projects
https://www.automationdirect.com/adc/...

ACC Automation
https://www.accautomation.ca
Helping you with your automation control tasks...
