M923A1 Spring Brake Chamber Swap
Автор: Iron Moose 5-Ton
Загружено: 2019-09-14
Просмотров: 2828
Описание:
Welcome to Iron Moose 5-Ton. This video explains what's involved in swapping out a "Spring Brake Chamber" on an M923A1. Any questions feel free to ask! We have attached some part numbers below for the items used.
Piggy Back Fail-Safe Spring Brake Chamber
-Military Part Number: A-3280-E-6817
-NSN #: 2530-01-134-3417
Chamber Clamp: (Used between service and spring brake housing..the one we replaced in the video.)
-Military Part #: 2797V100
-NSN #: 5340-00-015-7560
Service Side Brake Diaphragm. (Smaller ones)
-Air brake chamber diaphragm (Type 12, 5-15/32” diameter) for all M939 series front and rear service brakes. P/N 234226, AD17544, 031023. NSN 2530004302392.
Spring Brake Diaphragm if you're interested:
*NOT USED IN THIS VIDEO AND NOT RECOMMENDED!!!!*
-Air brake chamber diaphragm (Type 16, 6-13/64" diameter) P/N 234189, N20151. NSN 2530000282533. Fits M939 series fail-safe spring brakes.
