How To Make 3 Channel LED Chaser Circuit..Simple LED Chaser Circuit..

Описание: Friends in this circuit I will show you How To Make 3 Channel LED Chaser Circuit..Simple LED Chaser Circuit..Friends it is a very simple circuit and you can easily make this 3 channel led chaser circuit at your home..Friends in this circuit we will not use any ic..In this circuit we will use transistors and capacitors for making the led chaser circuit..Friends with this led chaser circuit we will connect 3 led channels..and we will connect 5 led's with every channel..Friends you can also connect more led's with this circuit if you want..Friends this led chaser circuit will work by 9 volt to 12 volt power supply..Friends in this video I will show you the complete process of making a 3 channel led chaser circuit step by step..Friends the led chaser circuit diagram is in the video please see the circuit diagram..So friends if you want to know how to make a 3 channel led chaser circuit at your home then watch the video and follow my instruction...Thanks..

Used Materials..
1 piece blank pcb board, 3 pieces 10k resistors, 3 pieces 1k resistors, 3 pieces BC547 transistors, 3 pieces 100uF capacitors, 15 pieces led...
