Simple 3-Channel LED Chaser Circuit Using BC547 Transistors
Автор: EmbedSpark Lab
Загружено: 2023-07-07
Просмотров: 551
Описание:
#experiment #diy #diyprojects #electronic #circuitdesign #proteus #pcbdesign #breadboard #simulation #arduino #555ic #arduinoproject #iotproject #nodemcu
This video we have learn how to create a circuit for 3 channel LED chaser circuit using BC547 transistors. This is the simple and intresting experiment for begineer level electrical and electronic students. Required components are given below
required components :
1) bread board - 1no
2) 9v Battery connector - 1 no
3) 470 ohm resistors - 3 no's
4) 10k ohm resistor - 3 no's
5) 1000 uF capacitor (or) 100uf capacitor - 3 no's
6) Red colour LED - 3 no's
7) Green colour LED - 3 no's
8) Blue colour LED - 3 no's
9) BC 547 npn transistors - 3 no's
10) 9V battery - 1 no
telegram link : https://t.me/mr_science_bro
Instagram : / mr_science_bro
previous video link : • led flasher circuit using bc547 transistor
