Introduction to Otto Cycle| Four-Stroke, Five-Event Cycle
Автор: JC Amores
Загружено: 2021-12-06
Просмотров: 1287
Описание:
Strokes - the movement of the piston (TDC to BDC and vice versa)
1. Intake Stroke
2. Compression Stroke
3. Power Stroke
4. Exhaust Stroke
Events
1. Intake - the air-fuel mixture is drawn inside the combustion chamber via the intake valve
2. Compression - the mixture is compressed for optimum burning
3. Ignition - electric spark from the spark plug ignites the fuel-air mixture
4. Power - burned and expanding gases drives the piston down to the TDC
5. Exhaust - burned gases are forced out of the combustion chamber via the exhaust valve
Otto Cycle
1 - 2: Isentropic Compression
2 - 3: Constant volume addition of heat
3 - 4: Isentropic Compression
4 - 1: Constant volume rejection of heat
