EUROLITE LED TMH-B60 Moving-Head Beam

Описание: Art.-nr.: 51786082
http://www.steinigke.de/?cl=details&a...

Moving Head Beam with 60 W COB LED in RGBW
¨ Moving Head Beam with 60 W COB LED in RGBW
¨ Compact lightweight
¨ Electronic dimmer
¨ Motion macros can be called up via DMX
¨ Strobe effects with adjustable speed
¨ 1 powerful LED 60 W COB (chip-on-board) 4in1 QCL RGBW (homogenous color mix)
¨ Positioning within 540° PAN and 180° TILT
¨ 4 integrated Showprograms
¨ Can be operated in 12; 14 CH mode
¨ The device is cooled by cooling fan
¨ Controlling by stand-alone; Sound to light via Microphone; Master/slave function; DMX; QuickDMX via USB (optional); CRMX by LumenRadio via USB (optional); W-DMX by wireless solution via USB (optional)
¨ Preprogrammed in Light´J; Light Captain
¨ Flicker-free
¨ Effect: Single Beam; Strobe effect
¨ With a beam angle of 2°
¨ 4 digits 7-segment LED display
¨ Rubber feet

Package contents
¨ 1 x moving light, 1 x user manual, 1 x power cord, 1 x omega bracket, 1 x safety eyelet




Power supply: 100-240 V AC, 50/60 Hz
Power consumption: 60 W
IP classification: IP20
Protection class: Protection class I
Power connection: Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided)
Fuse: 5 x 20 mm, T 1,5 A Fuse replaceable
Lamp type: LED lamp
LED: 1 x 60 W COB (chip-on-board) 4in1 QCL RGBW (homogenous color mix)
Max. TILT movement: 180° Positioning
Max. PAN movement: 540° Positioning
DMX channels: 12; 14
DMX input: 3-pin XLR (M) mounting version
DMX output: 3-pin XLR (F) mounting version
Cooling: Cooling fan
Control: Stand-alone; Sound to light via Microphone; Master/slave function; DMX; QuickDMX via USB (optional); CRMX by LumenRadio via USB (optional); W-DMX by wireless solution via USB (optional); Light´J; Light Captain
Beam angle: 2°
Beam angle (1/2 peak): 2°
Beam angle (1/10 peak): 5°
Illuminance in Lux (lx): Red (R) 1m: 19079 lx, 3m: 3275 lx, 6m: 838 lx
Green (G) 1m: 34129 lx, 3m: 5358 lx, 6m: 1372 lx
Blue (B) 1m: 3925 lx, 3m: 1084 lx, 6m: 277 lx
Cold white (CW) 1m: 48589 lx, 3m: 8089 lx, 6m: 2048 lx
All 3m: 17330 lx, 6m: 4405 lx
Housing color: Black
Display type: 4 digits 7-segment LED display
Transport aid: Rubber feet
Dimensions: Width: 17,5 cm
Depth: 15,0 cm
Height: 25,0 cm
Weight: 3,25 kg
