EE201 Circuit Theory I: Lecture 45 (Middle East Technical University, Fall 2020)
Автор: EE201 at METU
Загружено: 2021-02-04
Просмотров: 2228
Описание:
Lecture 45, EE201 Circuit Theory I (Fall 2020)
Instructor: Emre Tuna,
Department of Electrical and Electronics Engineering
Contents:
00:00 - Example I: First Order Circuit with Capacitor and Operational Amplifier
02:46 - Example I: Determine Initial Region - Spoiler: It is Linear
07:40 - Example I: Analyze the Circuit in the Linear Region
13:34 - Example I: Will It Go +Sat or -Sat?
20:12 - Example I: Sketch the Vc(t) and Vo(t)
24:53 - Example II: First Order Circuit with Inductors and Nonlinear Resistor
30:00 - Example II: Determine Initial Operating Region of Nonlinear Resistor
32:18 - Example II: Find the Time the Resistor changes Operating Region
35:12 - Example II: Determine the Characteristics under New Operating Region
39:06 - Example II: Find the Currents Passing through each Inductor
EE201 Circuit Theory I Fall 2020 Playlist:
• EE201@METU, Fall 2020
