Tutorial of UNI FAN TL & TL LCD Installation

Описание: Important Restrictions for Installation of UNI FAN TL Series:

Regarding the TL Controller:
1. Each port supports a maximum of 10 TL fans or 3 TL LCD fans.
2. Each controller supports a maximum of 16 fans, including up to 7 TL LCD fans.
3. The 1st port does not support TL LCD fans.
4. It's necessary to connect the 9-PIN USB 2.0 port directly to the motherboard, a splitter is not recommended.
5. If needed, connecting 2 controllers is allowed, with both requiring a direct connection to the motherboard. Do not connect more than 12 TL LCD fans to the entire system. For additional USB-connected products, use the LIAN LI USB 2.0 1-to-3 (Type A male port) splitter.
6. Ensure to update the TL series controller firmware by referring to the update guide: https://drive.google.com/file/d/1w93V...

Regarding TL fans:
1. When connecting 7 or more TL fans in a daisy chain, ensure RPM stability by using an additional power adapter connected to SATA. This adapter is exclusively included in the TL Triple pack.

Regarding TL LCD fans:
1. Connect the power cable to the pin side only.
2. Do not mount the LCD side facing inward to avoid potential damage to the screen.
3. Update the TL LCD firmware if encountering JPG file or rotation function memory issues; follow the guide: https://drive.google.com/file/d/1HgEE...
