Brake Job Tools: Dial Indicator

Описание: Visit our website for more resources geared towards technicians, DIYers and automobile enthusiasts: http://bit.ly/2pzelbU.

Doing a brake job requires special tools and materials. These tools are separate from the sockets, ratchets and air tools that you use every day in your shop. In the sixth part of our series, we talk about why taking the time to measure lateral runout with a dial indicator can save you a comeback.

Visit our Website: http://www.raybestos.com
Like us on Facebook:   / raybestosbra.  .
Follow us on Twitter:   / raybestosbrakes

Measuring lateral runout is an essential component of a quality brake job. If you don't take the time to measure lateral runout, you are at a higher risk of a comeback.

Checking Lateral Runout Steps:

1.) Slide conical washers over the studs of the wheel.
2.) Tighten down the lug nuts. It does not have to be to specifications. But you must tighten down the lug nuts evenly. We use the yellow torque stick (65 ft-lb).
3.) Install the dial indicator.
4.) Turn the rotor and measure the lateral runout. Check the rotor's runout against the specifications in your spec guide. Most modern vehicles have a lateral runout of .002.

Why Check Lateral Runout?

Even if you are installing a brand new rotor, it is critical that you check lateral runout. An issue with the hub assembly could cause excessive runout, even with a perfect rotor.

If you let a vehicle leave the shop with excessive lateral runout, there will be no problems at first. However, with today's tight tolerances, problems will soon occur.

Excessive lateral runout causes the rotor to wobble as it turns. An excessive runout of a few thousandths causes the rotor to make contact with the pads during every revolution. This contact occurs even when the brakes aren't applied. Over time, as the pads make contact with the same spot on the rotor, it results in a thickness variation. The thickness variation on the rotor's surface leads to pedal pulsation when braking.
