[DIY] camera gear, M42 to PL mount conversion adapter & Rear lens cap, 3D modleing & printing
Автор: Mountain Breeze Studio
Загружено: 2020-08-12
Просмотров: 4953
Описание:
This is a video about making your own camera gear, such as an adapter that converts a vintage m42 mount to an arri PL mount, and a rear lens cap.
It's a simple adapter to attach a vintage lens from the M42 mount to the PL mount, but unfortunately, the inner diameter of the PL mount is only 53mm, so the number of lenses on the M42 mount where this adapter is useful is very limited. (Helios-44-2 58mm f/2, etc.)
And due to the limitation of the filament material of 3D printers, durability and stability due to temperature changes are insufficient. Therefore, it may be insufficient for professional use, but I think it is useful to some extent for simple confirmation or hobby use.
See the link below for more information and print files.
https://surplusperson.tistory.com/746
File sharing is for sharing ideas with you. Use only for personal use. Non -commercial.
If you found my designs useful, please donate what you think it is worth to my paypal.me. Your donation will be useful for a new housing design on a variety of lenses.
https://paypal.me/suplusperson
빈티지 m42 마운트를 arri PL 마운트로 변환하는 어댑터, 후면 렌즈 캡 등을 포함하여 자신 만의 카메라 장비를 만드는 방법에 대한 비디오입니다.
M42 마운트의 빈티지 렌즈를 PL 마운트에 부착하는 간단한 어댑터이지만 안타깝게도 PL 마운트의 내경은 53mm에 불과하므로이 어댑터가 유용한 M42 마운트의 렌즈 수는 매우 제한적입니다. (Helios-44-2 58mm f / 2 등)
그리고 3D 프린터의 필라멘트 재질의 한계로 인해 온도 변화에 따른 내구성과 안정성이 부족합니다. 따라서 전문가 용으로는 부족할 수 있지만 간단한 확인이나 취미 용으로 어느 정도 유용하다고 생각합니다.
자세한 정보 및 인쇄 파일은 아래 링크를 참조하십시오.
https://surplusperson.tistory.com/746
파일 공유는 아이디어를 공유하기위한 것입니다. 개인적인 용도로만 사용하십시오. 상업적 사용은 허용되지 않습니다.
