Analogue Coach Lighting Interfering with DCC ABC braking?
Автор: Dongits Model Railway
Загружено: 2022-09-26
Просмотров: 1274
Описание:
Diagnosing a problem with Lit Pullman Coaches causing a train to fail to stop in an ABC braking section.
Do you want to make your own PCBs? Design a PCB yourself, and have it produced for you by PCBWay: [https://www.pcbway.com/setinvite.aspx...]
Also check out the PCBWay Community site at [https://www.pcbway.com/project/]
Two of these lit pullman coaches in the same train was interfering with the ability of a locomotive to stop in the ABC sections at the club layout. In this video I check out the DCC waveform with an oscilloscope as I see if I can reproduce the issue at home.
Do let me know in the comments what you think I should do with these coaches.
Table of Contents:
00:00 - The Problem
00:28 - DCC Waveform -- Data and ABC
00:47 - PCBWay
01:32 - DCC Waveform -- Noise
02:20 - Testing the coaches
04:33 - Disassembly to review lighting circuit
05:46 - Options for how to proceed
