Proteus Simulation: Door Lock system using 8051

Описание: #proteus #simulation #door #lock #system #electronics_projects
Proteus is simulation platform on which Door Lock System is simulated using 8051 micro controller and keypad.

Details:-
1. User will enter the password by using keypad which is interfaced with
Port 1 of 8051 Micro Controller.
2. LCD is interfaced with micro controller on Port 2 by 8 data pins.
3. Motor Driver IC L293D is used for controlling DC motor of 12V rating. It is interfaced with Port 3 of micro controller 8051.
4. RS (Register Select) and EN (Enable) Pins of LCD are connected to Port 3 and RW(Read-Write) pin is grounded only for writing purpose on LCD.
5. 12V battery is used to energies DC motor though IC293D.

Concept:-
1. Password is set 1234 by using programming.
2. If user entered correct password by means of keyboard then LCD will indicate correct and Motor will Rotate to open door.
3. If user entered incorrect password then LCD will display "Incorrect" and motor will not rotate, eventually door will not open.

Keil-Microvision 5 software is used for programming.

Please Find program below in link given:-
https://drive.google.com/file/d/1m5s6...

Special Thanks to Bensound for background score.
