How To: Terminate Shielded ezEX-RJ45 Connectors

Описание: This how to video details how to properly terminate a shielded Ethernet (CAT6/CAT6A) cable with the Platinum Tools ezEX-RJ45® Shielded connectors.

The shielded ezEX-RJ45 connectors are designed for larger cables and conductors. They feature a unique integrated Hi-Lo stagger load bar and allows ‘big’ conductors to pass through the front end of the connector making it easy to verify the wiring sequence before terminating. These connectors are typically used with CAT6 and CAT6A cables. Crimp tool for the ezEX-RJ45 connectors is the EXO Crimp Frame® and EXO-EX Die™ (100061C).

• Hi-Lo stagger to isolate each conductor
• Simple one piece/pass through design, no bars or liners
• Shielded 5e/6/6A compliant
• Insulation Diameter (Conductor)
ezEX™44 Connector Size range: 0.039” – 0.044” (1.0 –1.12mm)
ezEX™48 Connector Size range: 0.043” – 0.048” (1.09 –1.22mm)
• Max Outer Diameter
ezEX™44 Internal Ground - 0.280” (7.1mm)
ezEX™44 External Ground - 0.305” (7.75mm)
ezEX™48 External Ground - 0.305” (7.75mm)
• Solid or Stranded 24-22 AWG
• TAA, TIA, RoHS, UL & FCC compliant
• Made in USA

More ezEX-RJ45 Shielded Connector information: http://bit.ly/2BXf0tR
More EXO Crimp Tool information: http://bit.ly/2i3xhd4

Part Numbers of products used in video:
P/N 100061C - EXO Crimp Frame® with EXO-EX Die™ – http://bit.ly/2i3xhd4
P/N 100024C - ezEX™44 Shielded CAT6 Connector, Internal Ground – http://bit.ly/2Etn3QQ
P/N 100025C - ezEX™44 Shielded CAT6 Connector, External Ground – http://bit.ly/2Epg7jF
P/N 12360C - External Ground Crimp Tool – http://bit.ly/2GcMvGG
P/N 15015C - Cat 5/6 Cable Jacket Stripper – http://bit.ly/2EEl0bT
P/N 10526C - Professional Electrician's Scissors – http://bit.ly/2HhjiM7
