Installation Overview: Coyote 10 Inch Pedestal

Описание: COYOTE® 10" PEDESTAL

COYOTE Pedestals provide easy customization options to adapt to your fiber or copper splicing needs at each location in
your network. Each pedestal is pre-assembled and can be configured to accept various fiber optic splice tray types, fiber
or copper terminals, fiber cross-connect bulkheads, or management brackets for copper splices. In addition, the organizer
can be removed and a metal frame can be inserted into the base to attach fiber closures and cabinets, such as the COYOTE
STP-L, STP-XL, and COYOTE PedBox®, to provide additional protection for your splices. The versatility that COYOTE
Pedestals provide allow you to create the network you desire.

• Each pedestal size is pre-assembled with a base, automatic locking cover, and internal organizer with a grounding busbar
• Cover and base are manufactured out of a UV/FR stabilized material to withstand weathering
• Split base design for easy installation around pre-installed duct/cables and replacement of existing pedestals
• Automatic cover locking system (patented)
• Grounding busbar isolates connections and is equipped with a ground wire terminal (#4 – #10)
• Organizer can be configured for various fiber and copper applications - splicing, terminals, hardened connectivity, and
cross-connect applications
• Organizer can accommodate COYOTE Flip Trays, LITE-GRIP® Splice Trays, and Legacy Splice Trays
• Metal frame organizer can be ordered with dual offset brackets or STP PRO mounting brackets
• All fasteners are constructed of stainless steel to prohibit corrosion and can be secured or loosened with common tools
(216 can wrench, 1/4" nut driver, or Philips screwdriver)
• Designed and tested in accordance with GR-13-CORE requirements
