CONFIGURE XY Plot COMPONENT NB Designer

Описание: XY Plot reflects the correlation of two variables visually. If you want to
monitor the XY Plot reflecting the changes of address values, the NB Unit
can clearly display it only by using this component.
It is assumed that there are M channels and N XY Plot components for
the sampling points per page and the corresponding registers in PLC is
M×N×2, as shown below. X11, Y11, X12, Y12, ..., X1N, Y1N, ..., XM1,
YM1, ..., XMN, YMN Note For “Xij, Yij”, subscript “i” represents the
channel number, “j” represents the sampling point, and “Xij” represents
the coordinate value of sampling point “j” in the channel “i”.
