Thinkpad L14 Gen 2 20X1S00P00 I Upgrade Options SSD and RAM Slot

Описание: Detailed Specification


Processor Intel Core i7-1165G7 (4C / 8T, 2.8 / 4.7GHz, 12MB)
Graphics Integrated Intel Iris Xe Graphics functions as UHD Graphics
Chipset Intel SoC Platform
Memory 1x 8GB SO-DIMM DDR4-3200
Memory Slots Two DDR4 SO-DIMM slots, dual-channel capable
Max Memory Up to 64GB DDR4-3200
Storage 512GB SSD M.2 2280 PCIe 3.0x4 NVMe Opal
Storage Support
One SSD mode: one drive, 1x M.2 SSD
• M.2 2280 SSD up to 1TB


Card Reader MicroSD Reader
Optical None
Audio Chip High Definition (HD) Audio, Realtek ALC3287 codec
Speakers Stereo speakers, 2W x2, Dolby Audio Premium
Camera 720p with Privacy Shutter
Microphone 2x, Array
Battery Integrated 45Wh
Max Battery Life MobileMark 2018: 9.01 hr
JEITA 2.0: 11.815 hr
Power Adapter 45W USB-C (3-pin)


DESIGN
Display 14" FHD (1920x1080) IPS 250nits Anti-glare
Touchscreen None
Keyboard Non-backlit, Traditional Chinese
Case Color Black
Case Material PC + ABS (Top), PC + ABS (Bottom)
Dimensions (WxDxH) 331 x 235 x 20.4 mm (13.03 x 9.25 x 0.80 inches)
Weight 1.59 kg (3.49 lbs)


SOFTWARE
Operating System Windows 10 Pro 64, Traditional Chinese / English
Bundled Software None


CONNECTIVITY
Ethernet 100/1000M
WLAN + Bluetooth Intel AX200 11ax, 2x2 + BT5.2
WWAN None
SIM Card None
NFC None


Standard Ports
1x USB 3.2 Gen 1 (Always On)
1x Ethernet (RJ-45)
1x microSD card reader
1x Thunderbolt 4 / USB4 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort 1.4)
1x Headphone / microphone combo jack (3.5mm)
1x Side docking connector
1x USB-C 3.2 Gen 1 (support data transfer, Power Delivery 3.0 and DisplayPort 1.4)
1x HDMI 2.0
1x USB 3.2 Gen 1

Optional Ports (configured) 1x Smart card reader
Monitor Cable None
SECURITY & PRIVACY
Smart Card Reader Smart Card Reader
Security Chip Discrete TPM 2.0
Fingerprint Reader Touch Style, Match-on-Chip
Physical Locks Kensington Security Slot
Other Security Camera privacy shutter


MANAGEABILITY
System Management None


SERVICE
Base Warranty 3-year, Depot
Included Upgrade None


ACCESSORIES
Bundled Accessories None
CERTIFICATIONS
Green Certifications

EPEAT Gold
RoHS compliant
TCO
ENERGY STAR 8.0

Mil-Spec Test
MIL-STD-810H military test passed











––––––––––––––––––––––––––––––
