AK35 sound amplifier disassembled
Автор: florin01m
Загружено: 2024-06-05
Просмотров: 3068
Описание:
CS3817EO Chip is connected direct to speakers output is a copy of tpa3110
https://www.ti.com/product/TPA3110D2
it can go up to 2 x 15w RMS
15W 16V 8Ω TND+N 10%）/ channel
10W 13V 8Ω TND+N 10% / channel
30W 16V 4Ω TND+N 10%）in mono
not recommended 4 Ohm speakers even with heatsink
use 6 or 8 Ohm for safety
heatsink missing
power supply is 1.5 A 14v
with 6 Ohm speakers at 14v you can go up to 12.24 w per channel
I can add another amplifier tpa 3116 with bigger laptop power supply and use the case.
you will need a buck converter lm2596 to step down voltage for the display / Bluetooth module from 19.5 v laptop charger to 14v
