1988 Supra Build Ep 18: How to wire a 1JZ-GTE VVTi to a MK3 Supra pt 1 - (JZX100)

Описание: How to wire a 1JZ into a MK3 Supra.
OEM JZX100 1JZ-GTE VVTi wired into a pre-89 MA70.
Tachometer, oil pressure, coolant gauge, all fuel, ign, starter, alternator, etc and all 1JZ wiring.

I am building a super lightweight FR-S and a 1JZ swapped mk3 supra

Links
My thread on Supraforums: https://www.supraforums.com/threads/1...
Wiring Guide Excel: https://1drv.ms/x/s!AscZ1sUy7fc1gQDkS...
Tools
Multimeter - https://amzn.to/3yyFdeq
Electrical Tape - https://amzn.to/3nrIFRQ
Wire Stripper/Crimper - https://amzn.to/3ufnKF8
1/8" Heatshrink (used after soldering individual wires together) - https://amzn.to/3nsVQ4U
Raychem DR-25 Heatshrink (3/16", 1/4", 3/8", 1/2", 3/4", 1") - https://amzn.to/3y5A1gB
Alex Tech Wire Protective Sheething (1/4", 1/2", 1") - https://amzn.to/3a6Hiox
Pick Set - https://amzn.to/3Ny0l92
Resistors(includes 100K, 560, and 15K) - https://amzn.to/3adrHU2
Resistor (39K) - https://amzn.to/3ufvbwn



All music in this video is from the Youtube Audio Library.

Current 1988 Supra Build List
1988 Toyota Supra MA70
1JZ-GTE VVTi (JZX100)
CX Racing Intercooler Kit
CX Racing Downpipe 3"
Stock MK3 R154 swapped
Stock 4.3 LSD
Stock TEMS

Upcoming:
RSR Springs
Weds Sports 17x9 +25
Continental ExtremeContact DWS06 255/40ZR17
Mishimoto Lug Nuts & Wheel Locks



Timestamps
0:00:00 - Intro
0:01:28 - 01) Tools/Materials
0:08:10 - 02)7M Connectors
0:12:30 - 03) Connections
0:43:00 - 04) Deleting Unnecessary Connectors
0:50:10 - 05) More Deleting/Cleaning/Protecting
1:00:49 - 06) Reinstalling
1:01:30 - 07) Downpipe?
1:06:39 - 08) Resistors
1:12:37 - 09) Speedo Cable
1:15:54 - Installing Resistors
1:21:21 - 10) Testing
1:25:58 - Outro/Cruising Around
