Clapper Block Modeling and Assembly | Clopper Block Onshape 3D Modeling | Onshape Assembly, Modeling
Автор: Infotainment blog
Загружено: 2022-03-15
Просмотров: 6596
Описание:
Clapper block is a sub-assembly of the tool head of a shaping machine. It is used for holding the shaper cutting tool. The design of the clapper block is such that it relieves the tool during the return stroke.
Clapper block consists of a swivel plate, attached to the vertical slide of the tool head of the shaping machine. The drag release plate relieves the tool during the return stroke. The drag release plate carries the tool holder and the tool is fixed in it by means of the tool clamping screw. The washer is used over the drag release plate for providing even bearing surface to the tool.
