🌊 ANSYS Fluent Tutorial: One-Way Fluid-Structure Interaction

Описание: 🌐 Explore More:
🔗 https://arminhashemi.org/
🛠️ Need Help with a Project?
📩 https://arminhashemi.org/order-project/
📸 Follow Me on Instagram:
  / caewitharminhashemi
💼 Connect on LinkedIn:
  / cae-with-armin

🔧 ANSYS One-Way Fluid-Structure Interaction Tutorial 🌊
In this step-by-step tutorial, we demonstrate how to model a valve with fluid flowing through it using ANSYS Fluent and Static Structural systems. Learn how to set up one-way FSI, where fluid pressure is transferred to the solid structure for stress and deformation analysis.

📌 What You’ll Learn:

✅Extending inlet and outlet domains for better convergence
✅Setting up Fluent for fluid simulation
✅Coupling Fluent with Static Structural for FSI
✅Viewing results like velocity, pressure, stress, and deformation
✅Tips for handling warnings and optimizing your mesh

📊 Highlights:
✅Static pressure and velocity contour plotting
✅Von Mises stress distribution
✅Deformation visualization

This tutorial is ideal for beginners looking to understand FSI concepts or professionals seeking a practical workflow. For more engineering simulations, like, comment, and subscribe!


#ANSYS #Fluent #FSI #EngineeringSimulation #FluidStructureInteraction #CAE
0:00 2:16 Introduction
2:17 6:20 Geometry
6:21 8:38 Fluent Mesh
8:39 12:58 Fluent Setup
12:59 14:22 Geometry & Mesh of Structure
14:23 15:39 BCs and importing data
15:40 16:49 Results #CAEwithArmin
