THE ORGAN OF CAIRD HALL, DUNDEE, SCOTLAND

HARRISON & HARRISON, DURHAN 1923
REBUILT 1992

The organ was the first concert organ built by the Durham firm of Harrison & Harrison. It has 50 speaking stops and was installed in 1923.
The blind organist, Alfred Hollins was the advisor and consultant for the design of the organ and he gave the opening recital on 27th June 1923.

The organ was completely restored in 1991-92 by Harrison & Harrison and the pitch of the instrument was sharpened to make the organ playable with the visiting orchestras.

The exhaust pneumatic action has been restored in its entirety, and the original adjustable pistons, one on each division except the Orchestral,
which had two, allow for the pneumatic piston action to be fitted with an electronic memory.

The combination pedals have been removed and replaced with toe pistons. The Swell to Orchestral coupler was added in the rebuild.

Dundee City Council are delighted that part of Dundee’s cultural heritage has been restored for future generations.

SPECIFICATION

PEDAL ORGAN
1 Double Open Wood FFFF (from 2) 32
2 Open wood 16
3 Open Diapason (metal, leathered) 16
4 Geigen (from 22) 16
5 Salicional (from 12) 16
6 Sub Bass (from 23) 16
7 Octave wood (from 2) 8
8 Flute (from 23) 8
9 Ophicleide (metal) 16
10 Trombone (from 34) 16 [Enclosed in Orchestral]
11 Posaune (from 9) 8

ORCHESTRAL ORGAN [ENCLOSED]
12 Double Salicional (metal) 16
13 Viole [d’Orchestre] 8
14 Violes Celestes (to FF, 2 ranks) 8
15 Harmonic Flute 8
16 Concert Flute (harmonic) 4
17 Harmonic Piccolo 2
18 Cor Anglais 16
19 Corno di Bassetto 8
20 Orchestral Oboe 8
Tremulant
21 Tuba (unenclosed) 8

GREAT ORGAN
22 Double Geigen 16
23 Bourdon (wood and metal) 16
24 Large Open Diapason (leathered) 8
25 Small Open Diapason 8
26 Geigen 8
27 Hohl Flute (wood, open through) 8
28 Rohr Flute (wood and metal) 8
29 Octave 4
30 Wald Flute (wood) 4
31 Octave Quint 2 2/3
32 Super Octave 2
33 Harmonics 17 19 21 22 IV

34 Contra Tromba 16 [Enclosed in Orchestral]
35 Tromba 8 [Enclosed in Orchestral]
36 Octave Tromba 4 [Enclosed in Orchestral]

SWELL ORGAN [ENCLOSED]
37 Open Diapason 8
38 Stopped Diapason (wood) 8
39 Echo Salicional 8
40 Vox Angelica 8
41 Octave Geigen 4
42 Stopped flute (metal) 4
43 Fifteenth 2
44 Mixture 12 19 22 26 29 V
45 Oboe 8
46 Vox Humana 8
Tremulant
47 Double Trumpet 16
48 Trumpet 8
49 Horn 8
50 Clarion 4

COUPLERS
Great Reeds on Great
Great Reeds on Orchestral

The usual couplers are provided
The octave couplers do not carry through on this Swell to Orchestral coupler.

PISTONS & ACCESSORIES
8 each to three manuals and Pedals
8 general pistons (available on Swell toe pistons by rocking tablet)
8 memories to divisional pistons
8 memories to general pistons
Great and Pedal Combinations by rocking tablet

REVERSIBLES
Orchestral to Great (thumb and toe)
Swell to Great (thumb and toe)
32′ (thumb)
Swell to Pedal (thumb and toe)
Great to Pedal (thumb and toe)
Orchestral to Pedal (thumb and toe)
Pedal Ophicleide (toe)
Orchestral Tremulant (toe)
Swell Tremulant (toe)

WIND PRESSURES
Pedal flue-work 4″ to 6″
Pedal reeds 18″ and 20″
Orchestral flue-work and reeds 6″
Tuba 20″
Great flue-work 5″, reeds 18″
Swell flue-work and light reeds 5″
Swell chorus reeds 10″
Action 12″
