112" x 312" CRAVEN 60HP Engine Lathe, Got Machinery, Scott Machinery & Supply
Автор: gotmachinery
Загружено: 2011-10-19
Просмотров: 1235
Описание:
http://www.gotmachinery.com
FOR SALE:
http://gotmachinery.com/details/?112-... (ACTUAL LISTING)
112" x 312" CRAVEN 60HP, 2Steady Rests, 96" Face Plate w/4-Jaws, 2 Front & Rear Carriages, BH
SPECIFICATIONS:
Swing ...................... 112"
Center Distance ............ 312"
Max. Turning Diameter ...... 88"
Width of Bedways(4 Way) .... 120"
Spindle Speeds ............. 0.8-2.4 RPM; 1.9-5.87 RPM;5-15 RPM; 12-36 RPM
6 Feed Changes PR
Sliding .................... 1/32" to 3/8"
Surfacing .................. 1/80" to 1/7"
Motor ...................... 60 HP 300-900 RPM
EQUIPPED WITH
96" Faceplate with 4-Jaws
(2) Front Carriages
(2) Back Carriages
(2) Steady Rests
Toolpost Grinder
Tailstock
Dimensions & Weights:
Headstock: 154" x 108" high x 112" wide 35.000 lbs.
Bed section #1 23 ft long x 22 inches high x 10 ft
wide 32,000lbs.
Bed section #2 20 ft long x 22 inches high x 10 ft
wide 22,000lbs.
Other parts; (Tailstock, 2 steady rest, 4 carriages) 70,000 lbs
Scott Machinery & Supply
538 Elm St.
Helena, AL 35080
205-664-9644
