Extraction & Processing Eqpt Auction Lot 509 - 2019 FEYECON D&I SUPERCRITICAL CO2 EXTRACTION UNIT
Автор: Revelation Machinery
Загружено: 2026-03-04
Просмотров: 5
Описание:
2019 FEYECON D&I SUPERCRITICAL CO2 EXTRACTION UNIT - LIKE NEW CONDITION W/ SIEMENS CONTROLS #1
SN:5130-A
EXTRACTOR SPECIFICATIONS:
48.3 HORSEPOWER
480V
3PH
60HZ
250 FLA
CO2 CONNECTION SIZE: 0.5"
CO2 FLOW RATE: 80 LBS/HR
CHILLED WATER CONNECTION SIZE: 1.5"
CHILLED WATER CONNECTION FLOWRATE: 15 GPM
EQUIPPED WITH:
STAINLESS STEEL JACKETED EXTRACTION VESSELS SPECS:
X2 TOTAL
SPECS ARE WRITTEN FOR INDIVIDUAL TANKS
35 GALLONS
13" DIAMETER
70" TOTAL HEIGHT, 60" BETWEEN STRAIGHT SIDES
TANK BODY:
MAWP: 350/-5 BARG @ 100C (5,000 PSIG/ -72PSI @ 212F)
MDMT: 0C @ 350/-5 BARG (-32F @ 5,000 PSIG/ -72 PSIG)
TANK JACKET:
MAWP: 5 BARG @ 100C (72PSI @ 212F)
MDMT: 0C @ 5 BARG (-32F @ 72PSI)
PUMP SPECIFICATIONS:
2019 SPECK-KOLBENPUMPENFABRIK P52/51-300CZ PUMP
PUMP SPECIFICALLY DESIGNED FOR OPERATION WITH CO2
FLOW RATE (MAX): 13.5 GPM
OPERATING PRESSURE (MAX): 4,350 PSI
POWER REQUIREMENT: 40.2 HP
PUMP SPEED: 1000 RPM
WEIGHT (APPROX): 183 LBS
INLET TEMPERATURE: DOWN TO -40F (SPECIAL CO2 RATING)
MOTOR SPECIFICATIONS:
AC-MOTOREN GMBH ACM 225M-6/HE
460V 60HZ 36KW (48HP)
1170 RPM
DELTA T SYSTEMS KK-471S TEMPERATURE CONTROL UNIT
460V 3PH 60HZ
115A
90 KW
3 HORSEPOWER
DELTA T SYSTEMS KI451S TEMPERATURE CONTROL UNIT
460V 3PH 60HZ
80A
60KW
1.5 HORSEPOWER
OVERALL SKID DIMENSIONS: 19'L X 8'W X 8'T
THIS LOT ALSO INCLUDES BLACK SUPPORT BEAM FOR PIPING BEHIND EXTRACTOR
