Suction arm installation for welding fume extractor dust collector Shanghai Kaisen

Описание: Suction arm installation for welding fume extractor from Shanghai Kaisen Environmental Technology Co., Ltd.

The suction arm is used for a single work station in conjunction with a fan or for multi-user stations using ducting connected to a central extraction and filter unit. The extraction arm is designed for continuous use and is suitable for high levels of fume, smoke and dust such as welding fumes, gases, vapours, light dusts or motor vehicle exhaust fumes.

The internal joint suction arm consists of a parallelogram multi-joints framework supported by an internal spring, a glass fiber tube coated with high temperature resistant, corrosion resistant PVC on its interior and exterior sides with spiral steel wire frame.

Features:
● Persistent tightness
● Multiple inlet diameter optional
● Arm keeps position due to self-supporting design
● Fast operation due to particularly flexible adjustment
● User-friendly due to particularly smooth movement of the hood with one hand
● Various options to connect the exhaust arms to fans, stationary devices or via duct work to central extraction and filtration systems

2M--DN160MM
3M--DN160MM
2M--DN200MM
3M--DN200MM
2M--DN250MM
3M--DN250MM
Also, custom service available.

For more details, please contact [email protected]
