AC Dimmer Circuit Using Phase Angle Control

Описание: Dimmer circuits which utilize Phase Angle Control are used to efficiently adjust the AC power delivered to AC loads by controlling the conduction angle. In this element14 presents episode, Surbhika has developed this kind of circuit to enable her to dim commonly used AC light bulbs in her home. She found it an interesting DIY project, as it meant understanding one of the fundamental concepts in power electronics and control theory to create usable hardware that could be built on a budget.

Discuss the episode and ask Surbhika questions on the element14 Community! https://bit.ly/3o0Cqbk

Engage with the element14 presents team on the element14 Community - suggest builds, find project files, and see behind the scenes video: https://bit.ly/3tmdewv

Visit the element14 Community for more great activities and free hardware: https://bit.ly/3q6YMpu

Tech Spotlights: https://bit.ly/3qPrDhM
RoadTest and Reviews: https://bit.ly/3pV5Bux
Project14: https://bit.ly/31wbnJY

#0:00 Welcome to element14 presents
#0:41 Overview
#0:54 Working Principle
#3:44 Zero Crossing Detector Circuit
#4:44 AC Load Driver Circuit
#5:53 Testing
#7:13 Give Your Feedback
