Understand how the Vorecon operates in 2 min!
Автор: Voith Group
Загружено: 2022-01-26
Просмотров: 16139
Описание:
Find out where the VoreconNX is located in the driveline, and how it works...
The VoreconNX is located in the driveline between the drive motor and the driven machine. The input shaft is connected to the planet carrier of the planetary gear. A large proportion of the input power is transmitted to the planetary gear mechanically, which means it is transmitted almost loss-free.
In front of the planetary gear, a torque converter with adjustable guide vanes is found. The torque converter pump wheel is coupled with the input shaft and diverts a small amount of input power. Using the turbine wheel, the diverted power is transmitted to the planetary sun gear. Adjustable pump blades control the turbine wheel liquid flow together with the speed. Combined power from the planet carrier and sun gear flows through the planetary gear and is transmitted to the output gear stage.
