IMB Multifor - 9042 TRIS work unit for copper bars - cutting - punching - bending

Описание: Punching, bending and cutting copper bars, metal profiles and din-rails. All these operations with only one TRIS work unit!
Suitable for small and large quantities. Functional and time-saving, it makes the job easier!

9042 TRIS WORK UNIT (PATENTED) can be used with all MULTIFOR pumps and control units. It is extremely versatile for its different operations. Our tris unit is made up of :
– a practical tool change-over system.
– a hinged tool frame fully opening, which allows simple introduction and removal of bars.
– a millimetric adjustment on the piston, which regulates the stroke of the tools.
– a protractor for reading the bending angle of the bar (on request).

Once set up, this accessory can repeat the work cycle without checking every time lenghts and angles. These characteristics are patented.
In order to achieve the maximum working precision, as well as to save time, the tooling is mounted on a workbench, which has been designed specially to be rational and practical in operation. It has all the necessary adjustments and references in order to position quickly the work pieces, avoiding measurements and engravings.

Punching:
Copper bars, aluminium and steel bars, etc. with max. thickness 12 mm - Round holes from Ø 5 to Ø 25 mm - Oval holes from 7X13 mm to 18x25 mm
Fot higher thickness than 12 mm, please contact our Technical Department.
It is possible to achieve equidistant punching on bars of maximum width 120 mm. Using special punches, which have the automatic extraction from the bar, one obtains holes.

Bending:
Copper bars, aluminium and steel bars etc. with thickness from 3 mm to 12 mm and maximum width 120 mm.
On request, tools for 160 mm bars

Cutting:
Copper bars, aluminium and steel bars, etc. with thickness from 5 mm to 12 mm and max. width 120 mm. For higher width than 120 mm and with thicker material than 12 mm , please contact our Technical Department.
