99-01 F350 Boost Auto Mirror Install Part 3 of 3 Extend & Fold Modules

Описание: Description: 99-01 to 08-16 Style Full Power Mirror Upgrade using Boost Auto Custom Mirrors. Video is a Step by Step Install With Wiring. I’d like to thank Josh and the Boost Auto Team for trusting & providing their product for Install & Review.
Full Power Option as in the video. BoostAuto is the only manufacture with ALL these options in one mirror, anywhere!

Boost Auto Mirror Install Part 3 of 3.

Parts Used: Mirrors can be purchased with custom Options here; https://boostautoparts.com/collection...
Standard Boost Mirror Options are: Power Adj Mirror, Sig Lamp, Defrost & Manual Folding/Telescope. $419.95 With real Customer Service provided.
Full Optioned Boost Mirror as shown in the video: Black top Paint able. Chrome available. Switchback Lighting, Defrost, Power Fold & Power Extend.
1. Wire taps to properly wire in the mirrors.
2. https://boostautoparts.com/products/1... $1,161.85

Parts Needed/Used:
Boost Mirror 2016 to 99-01 Wiring Harness Adapter. Included with kit. Order by year.
Mirror Control Wiring Harness. Included with Mirrors.
Mirror Heat Wiring Harness if Optioned. Build one, parts list below.
Powered Folding & Extend Module if Optioned. Control Module Kit.

Mirror Heat Wiring Harness Parts:
Nilight Led Light Bar Wiring Harness Kit. Kit has Switch, Fuse, Wires, Relay and connectors. Model No: 10008W.
Heated Mirror control connector on Truck Wiring. PN: SP-5600 or 72-5600R ~ $8.39 only two needed (One per side). https://www.amazon.com/dp/B0BQMPGWWG
T-Tap 22-10 AWG Quick Splice Wire Terminal Combo Connectors Red, Blue & Yel Kit $11.59 https://www.ebay.com/itm/296337808472
Three Boost Autoparts Fuse Holder & Red Wire Tap PN: 1841F contact BoostAutoparts.com
Lighted Power Switch with Amber Colored Indicating dot PN: KCD1-5-101EN $4.99 https://www.ebay.com/itm/394346889128
3 x Blue Electrical Cable Connectors Quick Splice. Https://www.ebay.com/itm/295850826541
Box of Male & Female Crimp Terminals, Blue. https://www.ebay.com/itm/335387459989
3 x 12-10 Gauge Terminal Yellow T-Tap Connector Dorman 86433 Yellow $5.34. https://www.amazon.com/Dorman-86433-Y...
If needed. Door Mirror Control Connector Truck Wiring side. PN: 1U2Z-14S411-K or (O2 Sensor Connector 1992-2002 for Ford) Amazon https://www.amazon.com/Michigan-Motor...

Tools Used:
¼” (6.4mm) Driver Handle.
½” (13mm) Combo Wrench to Disconnect Battery.
9/32” (7mm) Socket ¼” drive.
7/32” (5.5mm) Socket ¼” drive.
7/16” (11mm) Socket 3/8” Drive.
3” Extension 3/8” Drive.
3/8” Drive Stubby Ratchet.
Wire Splice Strip Crimp Tool.
9” (228mm) Pliers. To seat T-Taps.
9” (228mm) Needle Nose Pliers with Side Cutter.
9” (228mm) Crescent or Adjustable Wrench.
No. 0 Phillips Screw Driver.
No. 1 Phillips Screw Driver.
No. 2 Phillips Screw Driver.
3/8” (9.5mm) Chuck Electric Drill.
7/64” (2.5mm) Drill Bits.
Harbor Freight Step Drill Bit. That has ¼” to ¾” step drill.
4” (100mm) Awe or something with a sharp point on it.
Car Body Clip Removal Tool.
Pencil to mark Heat Switch location.
Scissors.
Black Marker to mark Module hole locations.

Consumables Used:
Bag to hold screws/fasteners.
½” (13mm) Wide Masking Tape.
String 1/16” (1.5mm) 1 piece 10 ft. Pull Passenger wires through Doors & Dash.
String 1/16” (1.5mm) 2 Pieces of 5 ft. Pull wires from under Steering Wheel.
Metal Coat Hanger to feed String.
25 x 6” (15cm) long 1/8” (3mm) Wide Zip Ties.
3 long 8” Twist Ties.
3 short Bread Twist Ties.
Piece of White printer paper at least 5” x 3”.

Boost Auto Customer Support:
Support Number: (765) 831-2830
Support Email: [email protected]

Thanks for watching. If you liked the video or learned something, please give the video a Thumbs Up. Like to help my channel, Subscribe & ring the Bell button.
Best Wishes & Blessings. Keith Noneya

00:00 Introduction. 00:08 Module Kit Tour. 00:47 Drivers Module Mount. 02:29 Drivers Wire Routing. 04:59 Drivers Module Power. 05:42 Pass Module install review. 05:50 Pass Module Power. 06:58 Drivers Boost Mirror Install. 09:27 Drivers Wire Connecting. 09:53 99-01 to 02-07 & 08-16 Connectors. 10:41 Drivers Heat Harness Connect.12:02 Driver Harness Securing. 13:03 Pass Harness Securing. 14:40 Pass Door Dust Shield. 15:00 Pass Speaker Install. 15:24 Pass Door Panel. 17:00 Drivers Door Dust Shield. 17:28 Drivers Speaker. 18:04 Divers Door Panel. 18:47 Pass Kick Panel. 19:15 Glove Box kick Panel. 20:05 Trash Hook Install. 20:22 Glove Box Light. 20:43 Steering Clam-shell & Ignition. 22:38 Steering Kick Panel. 23:18 Park Light Test. 23:45 Turn Light Test. 24:04 Extend & Fold Test. 25:00 Why it so long. 25:47 Like & Subscribe.
