Описание: 1
1. Activator Installation
Issue: Activator installed in the incorrect location and not permanently secured. This prevented proper activator operation.
Resolution: Activator was reinstalled in the correct position per the manufacturer’s installation guide and permanently secured.
2. Activator Adjustment
Issue: Activator was not adjusted to work with the interior door handle and locking system.
Resolution: Activator was properly adjusted according to the installation guide.
3. Support Installation
Issue: Support installed too high and not per installation guide. The motor and rod interfered, preventing the door from closing properly and risking rod failure.
Resolution: Support was reinstalled in the correct lower position per installation guide.
4. Lock-to-Activator Cables
Issue: Cables were bent, preventing proper locking and unlocking.
Resolution: Cables were reorganized and installed correctly per installation guidelines.
5. Interior Door Handle Installation
Issue: Door handle installed incorrectly, preventing proper mechanical operation.
Resolution: Door handle was reinstalled to the manufacturer’s specified position.
6. Door Handle Module Wiring
Issue: Door handle module was not connected to the vehicle harness. The Ador system did not deactivate when the vehicle was locked, allowing motor engagement when pulling the exterior handle.
Resolution: Module connected to vehicle harness. When locked, the exterior handle is now deactivated and cannot open the door.

2
1. Activator Installation
Issue: Activator installed incorrectly and not permanently fixed.
Resolution: Activator reinstalled in the correct location per manufacturer’s installation guide and permanently secured.
2. Activator Adjustment
Issue: Activator not adjusted for interior handle and locking system operation.
Resolution: Activator adjusted according to installation guide.
3. Lock-to-Activator Cables
Issue: Cables bent, preventing proper locking/unlocking.
Resolution: Cables reorganized and installed per guidelines.
4. Door Contacts
Issue: Door contacts were loose and only connected properly when the door was closed.
Resolution: Contacts permanently fixed according to installation guide.
5. Door Handle Module Wiring
Issue: Door handle module not connected to vehicle harness; Ador system did not deactivate when locked.
Resolution: Module connected properly. Exterior handle now deactivates when vehicle is locked.

3
1. Activator Installation
Issue: Activator installed incorrectly and not permanently secured.
Resolution: Activator reinstalled correctly and permanently fixed per installation guide.
2. Activator Adjustment
Issue: Activator not adjusted for proper interaction with interior handle and locking system.
Resolution: Adjusted per installation guide.
3. Lock-to-Activator Cables
Issue: Bent cables prevented proper locking/unlocking.
Resolution: Cables reorganized and installed correctly.
4. Door Handle Module Wiring
Issue: Module not connected to vehicle harness; Ador system remained active when locked.
Resolution: Module connected; exterior handle now disabled when vehicle is locked.
5. Door Handle Mechanism
Issue: Door handle mechanism improperly installed, causing it to stick and drain battery power.
Resolution: Door handle removed, mechanically adjusted, and reinstalled correctly per guide. Battery replaced.
6. Door and Rail Adjustment
Work Performed: Door adjusted; rollers cleaned and rails lubricated to ensure smooth and faster operation.

Vehicle 4 – Repair Summary
1. Activator Installation
Issue: Activator installed incorrectly using an improper (small) screw and not permanently fixed.
Resolution: Activator reinstalled correctly per manufacturer’s installation guide and permanently secured.
2. Activator Adjustment
Issue: Activator not adjusted to work with interior handle and locking system.
Resolution: Adjusted according to installation guide.
3. Door Contact Wiring
Issue: Door contact wires connected incorrectly (not per installation guide).
Resolution: Wiring corrected per guide (green-to-green, blue-to-blue during door closing).
4. Missing Activator Spring
Issue: Activator installed without required spring, preventing proper locking/unlocking.
Resolution: Spring installed to ensure correct mechanism operation.
5. Lock-to-Activator Cables
Issue: Cables bent, preventing proper locking/unlocking.
Resolution: Cables reorganized and installed correctly.
6. Door Handle Module Wiring
Issue: Module not connected to vehicle harness; Ador system did not deactivate when locked.
Resolution: Module connected properly; exterior handle now disabled when vehicle is locked.
7. Door Contacts
Issue: Door contacts not installed or loose, preventing mechanism from stopping when door closed.
Resolution: Door contacts installed permanently per installation guide.
8. Door Handle Fastening
Issue: Door handle permanently installed with incorrect bolt, preventing disassembly for inspection. Bolt could not be removed.
Status: Door handle module works.
