Описание: 1. Eight equal drops of oil are falling through air with steady velocity of 0.1ms-1. The drops recombine to form a single drop, what should be the new terminal velocity?
2. Water travels through a 9.6 cm diameter fire hose with a speed of 1.3 m/s. At the end of the hose, the water flows out through a nozzle whose diameter is 2.5 cm. (a) What is the speed of the water coming out of the nozzle? (b) What diameter nozzle is required to give water speed of 21 m/s?
3. A fish tank has dimensions 0.30 m wide by 1.0 m long by 0.60 m high. If the filter should process all the water in the tank once every 3.0 h, what should the flow speed be in the 3.0 cm diameter input tube for the filter?
4. A venturi meter is measuring the flow of water; it has a main diameter of 3.5 cm tapering down to a throat diameter of 1.0 cm. If the pressure difference is measured to be 18 mm-Hg, what is the speed of the water entering the venturi throat?
5. A small circular hole 6.00 mm in diameter is cut in the side of a large water tank, 14.0 m below the water level in the tank. The top of the tank is open to the air. Find (a) the speed of efflux of the water and (b) the volume discharged per second.
6. What is the Aerofoil lift (in newtons) due to Bernoulli's principle on a paper plane of wing area 0.01 m2 if the air passes over the top and bottom surfaces at speeds of 9 m/s and 7 m/s respectively? (Take the density of air as 1.28 kg/m3.)
7. During a windstorm, a 25 m/s wind blows across the flat roof of a small home. Find the difference in pressure between the air inside the home and the air just above the roof, assuming the doors and windows of the house are closed. (The density of air is 1.28 kg/m3).
