Low Profile Scissor Lift Table with Ramp

Описание: Low Profile Scissor Lift Table with Ramp; 4 x Low Profile Single Scissor Lift Tables with auto level and stand. Lift capacity 1500kg with a platform size 1500mm x 1000mm closed height 85mm with a travel 715mm being total raised height 800mm. Ramp located at one short end to allow pallet truck to place and remove CHEP pallets. Lift speed 48mm/ sec and powered by 1.1kw (415V 3 phase) motor – remote power pack with cover and 2.5m hose control cable. Low Profile Single Scissor Lift Table supplied with automatic level adjustment with limit switch, photocell and thermal cut out and 2500mm wander lead. Safety trip bar on perimeter of platform - stops lift if an obstruction is met. Maintenance safety bars are included to mechanically lock the platform when raised for servicing. Standard Lifts are manufactured from mild steel painted RAL5015 Blue & 2003 Orange. Warranty - 1 year to cover Parts and Labour for customers on the U.K mainland. Lifts comply with the European Standard EN1570 and are CE marked. Scissor tables Issued with instruction/maintenance manual test certificate and certificate of conformity.

For a quotation please contact;
Manual Handling Solutions
58, Paige Close, Watlington,
King's Lynn, Norfolk PE33 0TQ
Tel 01553 811977
[email protected]
http://www.manualhandlingsolutions.co.uk
