How to verify Electrical Fast Transient Pulses - Capturing EFT/Burst Pulses EM Test Compact NX5
Автор: Transient Specialists
Загружено: 2021-11-08
Просмотров: 2370
Описание:
Video guide on how to conduct basic EFT pulse verification at 2 kV level using an EFT verification kit from direct out and CDN. Rent EFT/Burst Equipment:
https://transientspecialists.com/coll...
This brief video includes how to verify pulse width, pulse duration, and peak value or max value using both the 1k Ohm adapter and 50 Ohm adapter through the CDN and Burst out of the EM Test NX5. The methods in the video are only used for verification, not to be considered a calibration or indicative of calibration quality results.
Transient Specialists offers rentals of both transient generators and EFT or Burst verification accessories including the verification kits. Contact us below for a quote.
Contact us directly at [email protected]
▬ Contents of this video ▬▬▬▬▬▬▬▬▬▬
0:00 - Introduction
1:02 - Modifying EFT & CDN for Verification
2:00 - Verifying EFT Pulse - Burst Out 50 Ohm Attenuator
3:33 - Verifying EFT Pulse - CDN 1k Ohm Attenuator
4:50 - Closing Remarks
