How to draw hexagonal nut (Engineering drawing). Orthographic projection |Engineering and poetry|
Автор: Engineering And Poetry
Загружено: 2019-10-06
Просмотров: 318456
Описание:
#hexagonal_nut_in_hindi
1. How to draw hexagonal nut in hindi.
Full Concept explain for correct & easy
method.
2. Top, front and side view of hexagonal nut
3. Hexagonal nut drawing, Engineering Drawing, machine drawing, fastenings,
4. UP engineering colleges, Up polytechnic, haryana polytechnic, delhi engineering & polytechnic (GBPIT).
Here is some definition & terminology of hexagonal nut
a. Width across flat (W) = 1.5D+3
b. Thickness of nut (T) = 0.8D to D
c. Distance across corner = 2D
d. Radius of chamfer = 1.4D
• link for my previous video's
1].Base profile by Base circle method
• Gear profile by Base Circle method in hind...
2].Gear profile by Approximate method
• How to draw Gear profile by Approximate me...
3].Efficiency of Otto cycle deri derivation
• Otto cycle:- Efficiency of Otto cycle deri...
4].Efficiency of diesel cycle derivation
• Diesel cycle :- efficiency of diesel cycle...
5]. Plain Scale drawing
• Plain Scale drawing |Engineering Drawing| ...
