3D Sketch and Planes with Composite Curves Full Exercies
Автор: Solidworks Premium Tutorial
Загружено: 2020-05-10
Просмотров: 3637
Описание:
3D Sketch and Planes with Composite Curves
3D Sketch & Planes:
The Following Ecercies demonstration how several planes can be used to help define the direction of the 3D sketch Entities.
3D Sketch and Composite Curve:
A 3D sketch noramlly consists of lines and arcs in series , and Splines. You can use a 3D sketch as a sweep path, as a guide curve for a loft or sweep, a centerline for a loft, or as one of the key entities in a routing system.
The following exercies demonstrates how serveral 3D Sketches can be created and combinedd into 1 continuous composite Curve for use as a sweep Path.
