FPGA 32 - Transition-minimized differential signaling (TMDS) 1280x720p @60fps RGB video over HDMI

Описание: We're building a complete FPGA RTL design to generate transition-minimized differential signaling (TMDS) RGB video over HDMI with a resolution of 1280x720p at 60 frames per second.

In addition to using two IP blocks for clock synthesis and video timing generation, we'll code up three RTL modules. One to handle TMDS 8b10b data encoding. One to handle the serialization of encoded 10-bit TMDS data onto the channels over HDMI interface. The third top level module glues everything together enabling the transmission of red, green and blue video frames onto the HDMI interface.

At the end we'll program the FPGA on the pynq-z1 board and verify the result on a receiving HDMI monitor.
