16x4 EDFA Unboxing and Live Output Testing | Dual Synchronize JDSU Pump | Sharp Vision | Cable TV
Автор: Cable Splicer Tech
Загружено: 2022-05-06
Просмотров: 35965
Описание:
#edfa #cablesplicertech
In this Video ,
☑️ Watch a basic video and live test of 16 X 4 EDFA in this video gallery ...
Is this EDFA better available at a lower (33000) price?
☑️ Check out this video about the 16 X 4 ( 23 dBm ) EDFA
☑️ 16 X 4 EDFA பற்றிய ஒரு அடிப்படை வீடியோ மற்றும் நேரடி பரிசோதனையை இந்த வீடியோ தொகுப்பில் காணுங்கள்...
☑️ குறைந்த ( 33000 ) விலையில் கிடைக்கும் இந்த EDFA சிறந்ததா ? என காணுங்கள்
Product Specification
Brand Sharp
Model Name/Number EDFA-16x4-23
Noise Figure Less than or Equal to 5.0 dB
Operating Bandwidth 1535-1565 nm
Input optical Power Range +2 to -12 dBm
Output optical power per port 16 dBm
Output port 4
Total Pump power 23 dBm
Return Loss Greater than or Equal to 45 dB
Pump Leakage Power -30 dBm
Optical connector type FC/APC or SC/APC (Optional)
Power supply voltage AC160V 250V (50 Hz)
Consumption 30 W
Operating Temperature Range -5 - +55 Degree C
Maximum operating relative humidity 95% Max
Storage Temperature Range -30 - +70 Degree C
Dimension 483 x 340 x 44 mm
Product Description
Features :
High density Pump
Operating bandwidth 1535 ~ 1565nm
Output optical power per port: 16dbm
4 output port
Dual power supply
Use in FTTH Triple Play solutions
Low power consumption
Single Pump / Double Pump
Input optical range: -5 to -10dbm
Low noise, high output, high reliability professional equipment.
Best EDFA for CATV - MSO, LCO and FTTH Triple Play solution providers
👇🏻
