Garbage truck side loader lego technic
Автор: GuiliuG
Загружено: 2011-09-27
Просмотров: 17114
Описание: This is my contribution to setechnic contest. The hardest thing to build was the arm due to its particular kinematics. Moreover, the dustbin weights 50g and the arm had to be strong enough not to bend to much. The functions are : fake motor powered by rear axles, steering and others are pneumatic ( three movements for the arm,compactor, and liftable skip). For the compactor, a cylinder push or pull a rack, which drives a 12T. When the skip is down, the 12T, mounted on the axle of the compactor, is connected with the other 12T( on the frame) and the movement is possible..The truck probably seems strange to people who don't know real one. It's directly inspired from mack truck with a python arm and I advice you to tap on youtube : " garbage truck" to see the wonderful kinematic of the arm of these trucks. You can see some pictures of my MOC on my brickshelf galery : GuiliuG.
