How to build the Umma85 cinewhoop
Автор: Unboxingexperience7
Загружено: 2020-06-28
Просмотров: 3889
Описание:
Here is my take on Ummagawd's micro cinewhoop Umma85. I printed all TPU parts on my Ender 3d printer. The carbon top plate is still in shipping from China so I printed it in PETG. You can find the files for free on thingiverse. For electronics I decided to use my Diatone Mamba f411 AIO board and Flywoo 1202.5 motors from an older build. Works fine, you just need to drill larger 2mm holes in the props (I went for Gemfan 2035). It's quite a simple build. Most challenging is probably to find the right Betaflight motor setup. You need to rearrange board direction, motor numbers and motor directions. And don't forget to put the probs upside down on the motors! For the FPV setup I used a Runcam Nano 2 and the BetaFPV A01 VTX which fits perfectly. I'm happy how my build turned out. Still I'm not willing to destroy the casing of my GoPro Hero 7 black. So I removed the battery and powered it directly from the balance plug of a Tattu 450mAh 4s battery. You can watch my other video to see how it's done: • How to power a Gopro with Lipo balance plug
http://on.fb.me/unboxingexperience
