Tutankhamun - a 3D lenticular image
Автор: Sarah Cartwright
Загружено: 2020-05-07
Просмотров: 442
Описание:
This one took me a while to make.
It's comprised of 17 3D renders that are interleaved together, and then printed at 600DPI.
The image interleaves have to exactly match the lens-width of the lenticular sheet, and that for me was 39.836 lines per inch... (not the straight 40 DPI) yep - I had to be that precise.
Once the pitch is fine-tuned, and the images are combined and printed, all you have to do then is slap the lenticular sheet on top.
----------------------------------------------------------------
Egyptian Tutankhamun model:
By skwtchinbane.
https://3dwarehouse.sketchup.com/mode...
Graphics software:
Thea Render
https://www.thearender.com/
Printed using:
Photoshop CC 2019, at 600 DPI
Lenticular image generator (last updated in 2004 :( ):
Lentikit is old - but it's FREE and gave me the best results!
http://lentikit.sourceforge.net/index...
Printer:
Dell C16060w color LED laser printer. Super cheap, & doesn't dry out with infrequent use.
Lenticular sheets:
Pacur star plus : 40 Lines per inch.
https://static1.squarespace.com/stati...
Indirectly bought from:
https://store.vuethru.com/flip-20x28-...
10 sheets of 50 x 71cm 40 LPI is £60. Getting small sheets is really difficult!
