HOW TO REPLACE A FORK SEAL, SHOWN ON A HONDA NSC50 VISION SCOOTER MOPED.
Автор: Hoojies Garage
Загружено: 2024-05-01
Просмотров: 1153
Описание:
Long video, play it at double speed :-) The fork seals used have the following dimensions:
26 x 37 x 10,5 millimeters.
They are made by Athena, part number P40FORK455204.
The oil quantity in each fork leg is just over 50 ml.
The Honda dealer recommended 15W oil.
The fork bellows are for a PGO fork for the following versions:
PGO Big Max
PGO Hot 50 12" wheel 3 spoke
PGO Hot50 10" wheel
PGO Tornado
They are made by Stylepro, part number: KGI-BM011980
The bellow has the following dimensions:
Length, 110 mm.
Fork leg diameter, 27 mm (easily compressed to 26 mm).
Lower inner diameter, 43 mm (easily expands over the aluminium casting).
The corrosion on the fork legs was removed by applying phosphoric acid gel rust remover.
How to install (remove if played backwards) the front wheel is also shown at the end of this video.
