AC75 RC 2 | Traveller & Rudder & Foil Pitch
Автор: skeed! RC
Загружено: 2024-12-20
Просмотров: 723
Описание:
Here is the second part: The control of the traveler, rudder and the servo for the foil flaps.
The traveler itself is a sliding sleeve which slides on a carbon tube. The sheet is guided by a ball bearing in a 3D printed holder made of PLA. The servo is again a Ditex TD1005S which is probably too weak. It remains to be seen whether a sail winch will finally be used here.
The rudder itself has a 6mm axle (titanium) which is guided from below by a ball joint glued into the fuselage. The lateral supports prevent wobbling under load. The axis is also connected to the rudder pitch servo via a ball joint and is then connected to the servo via a carbon rod. The servo for the rudder is then superimposed with the movement of the pitch servo via the remote control so that no steering movement occurs when adjusting the pitch.
The small servos under the foil arm holders control the flaps on the foils via a Bowden cable. These will follow in one of the next episodes.
