Free and Open Source CAD/CAM Toolchain
Автор: Christoph Wagner
Загружено: 2016-07-30
Просмотров: 44176
Описание:
============== Description ==============
This is a showcase of the open source toolchain I use for SIMPLE CNC projects.
In this example I'm making a tool rack for my lathe.
============== Software ==============
CAE LINUX
I'm running my CAD/CAM software in a virtual box with CAELinux on top. Unfortunately this distro seems to not be under active development. The base system is pretty old (Kubuntu 12.04) but it packs a whole lot of useful engineering tools.
http://caelinux.com/CMS/
FREECAD
Freecad is a quite usable and rapidly improving CAD tool for personal application.
The Path module is pretty new and therefore just has basic functionality’s. The same argument can be made for the Assembly module.
http://www.freecadweb.org/
OpenSCAM
The tool of choice for G-Code evaluation
http://camotics.org/
============== The CNC Machine ==============
I use a low cost, DIY CNC router which is driven by LinuxCNC.
LinuxCNC is a Debian distro with a realtime kernel and specific software for machinist.
The included G-Code interpreter is comparable to Mach3 and very flexible and configurable.
http://linuxcnc.org/
============== Further Questions ==============
Feel free to leave a comment.
============== Soundtrack ==============
https://lmms.io/lsp/?action=browse&us...
