How to Replace a Sump Gasket Ford Mondeo MK3 ST220

Описание: How to replace a Sump gasket ford mondeo mk3 st220,

First your need to get the car in the air and support it on axle stands, ( i removed the front driver wheel for better access) and remove the front flexi pipe, held in place but 2 15mm nuts and 2 15mm from flexi to exhaust.

once this is out the way your need to remove the bracket on the back off the sump by removing the 2 10mm nuts.

Then there are 15, 13mm bolts some are studs so your need a 13mm deep socket for these. There are 2 13mm bolts that go into the bell housing.

This job was simple to do, but due to some rusted rivet bolts on the flexi pipe it made this job that little harder. I ended up having to cut out the two bolts on the flexi and replaced them with 2 17mm bolts (video to follow on that one)

When doing up the sump bolts, torque to 26nm and start with bolt 1 first working around to 15.

Tools needed:
15mm for front flexi pipe removal
10mm for flexi pipe bracket on sump
13mm for the 15 bolts on the sump itself
13mm deep socket for stud removal
Trolly jack and wood for support of the sump
Some fresh Oil (i used Halfords 5w30)
Bit of cardboard to number bolt replace location
