Q. 5.18: Design a sequential circuit with two JK flip-flops A and B and two inputs E and F. If E = 0
Автор: Dr. Dhiman (Learn the art of problem solving)
Загружено: 2020-05-01
Просмотров: 71010
Описание:
Q. 5.18: Design a sequential circuit with two JK flip-flops A and B and two inputs E and F. If E = 0, the circuit remains in the same state regardless of the value of F. When E = 1 and F = 1, the circuit goes through the state transitions from 00 to 01, to 10, to 11, back to 00, and repeats. When E = 1 and F = 0, the circuit goes through the state transitions from 00 to 11, to 10, to 01, back to 00, and repeats. What is the role f the E input?
Please subscribe to my channel.
Wish you success,
Dhiman Kakati
(let's learn together)
