How To Fix A Furrion Microwave. What fuses I Used That Worked. And A Bonus Update.

Описание: Need some help on fixing a furrion microwave/convection oven.? Tune in as I show you the inner workings of the furion microwave model number FMCM15-SS.

Furrion RV Microwaves - FMCM15SS
1.5 Cubic Feet
Convection Microwave
Over the Range Microwave
Furrion
29-15/16W x 16-3/8T x 15D Inch
Stainless Steel
1500 Watts
Cook, bake, and brown food in your RV with this convection microwave oven. 2-Speed exhaust fan with filters removes unwanted odors, smoke, and moisture. Optional metal shelf and standing rack give you extra cooking space.


Features:

Over-the-range microwave has 3 auto-cook settings and 10 power levels to heat food
Convection cooking has 10 temperature settings to bake and brown foods
Touch control panel has a control lock to prevent accidental use
LED display shows the timer, clock, and other activated functions
Removable metal shelf gives 2 levels of space for convection and combination cooking
Glass turntable with optional wire rack microwaves food evenly
2-Speed exhaust fan removes smoke, steam, and odors
Removable ventilation filters catch grease and exhaust
Oven and surface lights provide illumination within the microwave and onto counter below
Includes 30-watt appliance bulbs
Durable, stainless-steel construction is vibration and corrosion resistant
Easy installation with included templates and hardware
Includes rear wall and top cabinet templates


Specs:

Dimensions:
Overall: 29-15/16" wide x 16-3/8" tall x 15" deep
Interior: 19-1/2" wide x 8-7/8" tall x 13-5/8" deep
Cutout width: 30" minimum
Capacity: 1.5 cu ft
Rated output power:
Microwave: 900 watts
Convection: 1,450 watts
Rated input power: 1,500 watts
Voltage: 120V/60Hz
Exhaust fan: 300 CFM
Turntable diameter: 13-5/8"
Weight: 69.4 lbs
1-Year warranty


The all-in-one design of Furrion's over-the-range convection microwave oven saves on space in your RV and utilizes both convection and microwave cooking. It also combines the two cooking modes to cook food quickly and to bring out the best flavor. The integrated exhaust fan and filters disperse odors, smoke, and moisture, keeping your RV interior and air quality clean.


Convection vs Microwave vs Combination Cooking

Convection cooking distributes and circulates heat throughout the microwave oven, which not only heats the air, but pushes it around to cook the food quicker and more efficiently than a standard microwave. This type of cooking is best for baking and browning foods, such as cookies, cakes, pastries, quiches, and soufflés.


Microwave cooking targets the liquids inside the food, stirring up the molecules in the liquid to heat food quickly and thoroughly. This type of cooking is best for anything with a high amount of liquid in it, such as beverages, soups, and frozen foods.


Combination cooking utilizes the energy from microwave cooking to cook food quickly, and the browning aspect of convection to cook food thoroughly. This works best with foods that take a long time to prepare, such as meats, casseroles, and breads. The included metal shelf provides good air circulation and even browning, producing the best results for cooking in your RV.


Cleaning the Filters

The easily removable charcoal and exhaust filters located on the top and bottom of the microwave catch grease and exhaust. To remove, simply slide the filter back and pull down. To clean, run the filter under hot water and use a mild detergent.
