CADWorx Steel - Single Line Steel
Автор: You Can Draft!
Загружено: 2021-03-09
Просмотров: 1483
Описание:
This video goes over the process of creating and modifying a drawing layout using the single line steel palette in CADWorx Steel.
At 10:10 in the video I add a linetype to the drawing and it doesn't show in the SLS palette. This can be remedied by restarting AutoCAD.
00:00 Prep Work - Layer Management
02:16 Prep Work - Creating a View/Layout
03:35 Intro to Single Line Steel (SLS) Palette
05:23 Generating Viewports
06:45 Creating a Config - New Layers
07:21 Creating a Config - Lines
08:05 Creating a Config - Tags
09:09 Creating a Config - Symbols
11:29 Adding a Named Setting
12:26 Applying Settings to Existing SLS
14:48 Updating a Named Setting
15:15 Applying Settings to Existing SLS (cont'd)
15:55 Preventing Members From Being Generated
18:16 Updating Viewport
21:40 Adjusting Gap Distance For Lines
23:58 Applying Settings to Existing SLS (cont'd)
27:14 Creating an Additional View/Named Setting
34:26 Saving/Opening Settings (external file)
35:12 Dimensioning to Single Line Steel
37:24 Remaining icons
