ANSYS Fluent Tutorial | Fluid Flow in a Constricted Passage | ANSYS R19 Tutorial | Constricted Flow
Автор: Ansys-Tutor
Загружено: 2019-08-31
Просмотров: 32169
Описание:
In the current tutorial, there is a fluid flow in a pipe, the pipe cross-section is uniform up to a certain extent and then it gets decreased by half, and due to decrease in cross-section, there is flow constriction. Due to this, there are variations in velocity, which has been analyzed. The possibility of a wake region near the outlet has also been found out.
What will you learn?
Use of fillet, Revolve tool to create the geometry.
Meshing: skewness change, Use of Refinement
Solver Setup
Find the wake formation region in post-processing
