EL34 Push Pull Amplifier; Power Transformer Calculation, Procedure & Examples
Автор: EL34_eRke
Загружено: 2024-05-24
Просмотров: 1073
Описание:
A Serial of several short Video Documents will describe Simple, Practical Design Procedure for Push Pull Amplifier based on EL34 tube.
It will be addressed:
Output Transformer, Zpp Selection and Transformer Calculation
Choke (Inductor) Design and Calculation
Power Tube Biasing
Power Tube Limits Analyzing
DC Coupled Pre Amp & Phase Splitter; Differential Driver; Design, Biasing and Gain Calculation
Grounding Connection for Hum Suppression
Chapters:
0:00 Intro
0:28 Example 1 Design
2:07 Example 1; Design Summary
2:45 Example 2 design
4:06 Example 2; Design Summary 4
4:22 Appendix
5:56 Bonus; 1st DIY Design
6:007 Project Related Doc.
