Paradox SP6000 program guide.

Описание: This video shows program steps about time and date setting, delay setting, setting for GSM module to send text message and setting for voice dallier.

Features
• 32 zones (any of which can be wireless or keypad zones).
• 32 users and 32 remote controls (one per user).
• In-field upgrades: Update the panel's firmware by connecting it to a PC via a 307USB Interface and then using the Winload
software (V2.80 or higher).
• Menu-driven programming for the Installer, Master, and Maintenance codes. This enables you to program the panel through a
simple and easy to use interface, without the use of section numbers.
• Multiple telephone numbers for event reporting: Three for the monitoring station, five for personal dialing and one for pager
reporting.
• Calendar with daylight savings time (enable section [730], option [1] and choose section [731] to put in the Country Code):
You can now select 1 out of 18 different country groups each with its own preprogrammed local daylight savings time. You can
also customize the daylight saving time by programming sections [732] and [733].
• New Sleep arming method: Similar to Stay arming, Sleep arming allows users to remain in a protected area, but provides a
higher level of protection. For example, in a two-story house, the perimeter is protected with Stay arming. With Sleep arming,
the perimeter as well as the main floor is protected (motion detectors, etc.), allowing you to roam the second floor and sleeping
quarters.
• Connect up to 15 hardwire keypads on the 4-wire communication bus.
• Push button power reset: Convenient reset button saves time when a momentary powerdown is required as opposed to having
to physically disconnect the control panel's power cables. Press and hold the RESET switch for five seconds. The STATUS
LED will start flashing. Within 2 seconds of this flashing, press the reset switch again. The panel will reset to default and
restart. Also, you can reset all programmable sections to factory default values in section [950].
• Available in 433MHz or 868MHz.
• Supports Memory Key (PMC-4 and PMC5).
• RF jamming supervision (section [700], option [5]): The control panel will report a trouble if the RF signal is being jammed.
• Supports SIA reporting format to central station.

Specifications
1.2.1 Magellan / Spectra SP Control Panels
• AC Power: 16Vac transformer (refer to Table 1 on page 3) with minimum 20VA rating
(Rec. 40VA), 50 to 60Hz
• Battery: 12Vdc, 4Ah/7Ah
• Aux. Power:* 600mA typical, 700mA maximum, fuseless shutdown @ 1.1A
• Bell Output:** 1A, fuseless shutdown @ 3A
• PGMs: 100mA low-current output (each PGM)
MG5000/SP5500/SP6000 = 2 on-board PGMs†
MG5050/SP7000 = 4 on-board PGMs
1.2.2 Magellan / Spectra SP Keypads
• Power input: Typically 9-16Vdc
• Current Consumption MG32LED: 170mA, MG10LEDV/H: 95mA, MG32LRF: 40mA,
MG32LCD: 110mA
• 1 standard keypad zone
• On-board anti-tamper switch (optional)
• Maximum Range Maximum run of wire is 230m (750 feet)
