Oppo A5 / A9 2020 Fake Charging FIXED! (Short on DP/DN Line)

Описание: Struggling with your Oppo A5 or A9 (2020) showing "Charging" but the battery percentage doesn't increase? You're not alone! This is a very common issue known as "Fake Charging."

In this detailed repair guide, I walk you through the step-by-step process of diagnosing and fixing this problem on the Oppo A5/A9 2020 motherboard. The root cause was a short circuit on the DN (Data Negative) line of the USB charging port circuit.

🔧 What Was The Problem? The phone would show a charging symbol but would not actually charge the battery.Using a thermal camera and a multimeter, we traced the short to a failed protection diode near the USB port controller. The DP (Data Positive) line was okay, but the DN line was shorted to ground.

✅ The Solution: We successfully removed the faulty protection diode,which eliminated the short circuit entirely. After this micro-soldering repair, the phone began charging perfectly and normally.

⚠️ Important Disclaimer: This is an advanced hardware-level repair.It requires expertise in micro-soldering, the right tools (microscope, soldering station, flux), and a good understanding of motherboard circuitry. If you are not confident, please take your device to a professional repair technician. I am not responsible for any damage you may cause to your device.

⏱️ Timestamps:
0:00- Intro & The Fake Charging Symptom
1:04- Initial Diagnosis with a Multimeter
2:10- Fake Charging Solution in Qualcomm Phone due to DP / DN line short
3:06- Oppo A5 2020 Charging Schematics
6:05- Locating the Faulty Protection Diode
8:41- Testing for Shorts After Removal
10:30- Reassembly & Final Charging Test

📱 Phone Models Affected: This repair is specifically targeted for the:

· Oppo A5 2020 (CPH1931, CPH1951)
· Oppo A9 2020 (CPH1937, CPH1941)
· The logic board and charging circuit are very similar in these models.

🛠️ Tools Used in This Video:

· DC Power Supply
· Digital Multimeter
· Microscope
· Precision Soldering Iron
· High-Quality Flux and Solder

oppo a5 2020 not charging,oppo a9 2020 charging symbol but percentage not increasing, usb dn line short, charging ic problem, usb protection diode short, how to remove short circuit from mobile phone, micro-soldering repair, phone repair tutorial, motherboard level repair, vcom diode short.

#OPPO #Repair #Microsoldering #FakeCharging #OppoA5 #OppoA92020 #PhoneRepair #DIYRepair #HardwareRepair #ChargingIssue #USBShort #MotherboardRepair

🔔 Subscribe for more free repair tutorials! Hit the bell icon to get notified whenever we post a new detailed repair video.Thanks for watching!

---
